Configuring Upload Types¶

Upload types define the categories of files that users can upload through the VOR Workbench. Each upload type appears as an option in the dropdown on the Uploads screen (e.g., macro-economic scenarios, portfolio data, transition matrices, model unit testing data).

Upload Type Fields¶

Each upload type is defined by the following fields:

Field	Description
`type_cd`	Primary key. A short code identifying the upload type (e.g., `ME_SCEN`). Maximum 32 characters.
`name`	Display name shown in the UI dropdown (e.g., "Macro Economic Scenarios"). Maximum 128 characters.
`upload_txt_search`	Not actively used. Must be unique in combination with `type_cd`. Maximum 32 characters.
`run_study_display`	If `true`, the upload type appears as a filter option on the Run Study Data tab.
`binary_only_upload`	If `true`, files are stored as binary blobs — upload preview and the info tab are disabled on the Uploads screen.
`info_tab_required`	If `true` and `binary_only_upload` is `false`, the UI requires users to fill out the info tab when uploading.
`upload_type_permission`	Optional. A foreign key to a Django permission that gates access to this specific upload type. See Per-Type Permission Gating.

Creating Upload Types¶

Upload types can be created through the REST API or by loading fixture files.

Via the REST API¶

Upload types are managed through the /upload-type/ endpoint. You can use the browsable API to create and edit upload types:

Navigate to the Administration UI (see Navigating to the VOR Workbench Administration UI).
Click View Site to open the browsable API.
Navigate to /upload-type/.
Use the form at the bottom of the page to submit a new upload type.

Alternatively, use a direct API call:

curl -X POST https://<django-host>/upload-type/ \
  -H "Authorization: Bearer $(vor create token)" \
  -H "Content-Type: application/json" \
  -d '{
    "type_cd": "MY_TYPE",
    "name": "My Upload Type",
    "upload_txt_search": "mytype",
    "run_study_display": false,
    "binary_only_upload": true,
    "info_tab_required": false
  }'

Via Fixtures¶

Upload types can be defined as YAML fixture files and loaded during deployment or manually. Below is an example fixture that defines two upload types:

- model: upload.uploadtype
  pk: ME_SCEN
  fields:
    name: Macro Economic Scenarios
    upload_txt_search: Scenario
    processed: "2021-07-21 00:00:00+00:00"
    run_study_display: true
    binary_only_upload: false
    info_tab_required: false
    upload_type_permission: null
- model: upload.uploadtype
  pk: MODEL_UNIT
  fields:
    name: Model Unit Test Data
    upload_txt_search: model
    processed: "2021-07-21 00:00:00+00:00"
    run_study_display: false
    binary_only_upload: true
    info_tab_required: false
    upload_type_permission: null

To load a fixture manually, SSH into the Django server and run:

su - vrisk
export VOR_DJANGO_CONFIG=/opt/vor/etc/django/config.json
cd /opt/vor/django
venv/bin/python src/manage.py loaddata <fixture_file>

PostgreSQL Environments

If your installation uses PostgreSQL, you must also set the library path:

export LD_LIBRARY_PATH=/opt/vor/pgsql/lib

Loading Sample Upload Types During Deployment¶

VOR Stream ships with a sample fixture at django/fixtures/upload_type.yaml. This fixture is not loaded by default. To include it during deployment, add upload_type to the django_fixtures variable in your Ansible inventory file:

django_fixtures=auth filter_type script_syntax help_docs patch_notes upload_type

See the Inventory File documentation for more details on the django_fixtures variable.

Per-Type Permission Gating¶

By default, any user with the Can view upload type permission can see all upload types in the dropdown. To restrict a specific upload type to certain users, you can link it to a Django permission using the upload_type_permission field.

When an upload type has a permission assigned:

Only users who have that permission (directly or through a group) will see the upload type in the dropdown.
The permission codename is returned in the API response for each upload type, allowing the UI to filter the list accordingly.

To configure this:

Create a custom permission in Django (or use an existing one).
Edit the upload type in the Django Administration UI and set the Upload type permission field to the desired permission.
Assign that permission to the appropriate user groups.

Tip

Setting upload_type_permission to empty (null) means the upload type is visible to all users who have access to the Uploads module.

Playpen Scoping¶

Upload types can optionally be scoped to specific playpens using the Upload type x playpen association. This controls which upload types appear in the dropdown for users working in a particular playpen.

The scoping logic:

If playpen-specific upload types exist for the user's current playpen, only those types are shown.
If no playpen-specific upload types exist, all upload types that are not assigned to any playpen are shown instead.

To assign upload types to a playpen:

In the Django Administration UI, navigate to Upload > Upload type x playpens.
Click Add upload type x playpen.
Select the upload type and the target playpen, then click Save.

This is useful in multi-tenant environments where different playpens serve different business functions and require distinct sets of upload types.

Custom Validation¶

Each upload type can have custom validation logic that runs automatically when a user uploads a file. Validation rules are defined by creating a class named <type_cd>_ValidationRule in the validation_overrides.py file.

For details on implementing custom validation, see Custom Upload Validation.

Required Permissions¶

Users need the following permissions to work with upload types. For the full permissions reference, see User Permissions & Groups.

View upload types

upload | upload type | Can view upload type

Manage upload types

upload | upload type | Can add upload type
upload | upload type | Can change upload type
upload | upload type | Can delete upload type

View playpen scoping

upload | upload type x playpen | Can view upload type x playpen

Manage playpen scoping

upload | upload type x playpen | Can add upload type x playpen
upload | upload type x playpen | Can change upload type x playpen
upload | upload type x playpen | Can delete upload type x playpen
